Specs
Aircraft
Weight (without payload)
55.2kg (with Lifting system)
60.2kg (with Winch system)
Excludes the weight of the battery, dual battery compartment and accessories, cable, and hook.
Max Takeoff Weight
170kg
The 170kg maximum takeoff weight is the performance specification of the drone. Please follow local laws and regulations in actual use. In the following countries and regions the maximum takeoff weight is restricted to 150kg: Brazil, Japan, Australia, Turkey, Saudi Arabia.
Max Diagonal Wheelbase（motor to motor）
2330mm
Diagonal length (tip to tip)
3904mm
Dimensions (arms & propellers unfolded)
3220mm × 3224mm × 975mm
Overall dimensions arms folded, propellers unfolded)
1820mm × 1840mm × 975mm
Overall dimensions (arms & propellers unfolded)
1105 mm × 1265 mm × 975 mm
Folding Method
Towards body
Loadable Battery Quantity
Supports dual battery and single battery configurations
Single battery Mode is for emergency use.
Max Flight Distance
Under 149.9kg takeoff weight: dual battery 12 km, single battery 6 km
This data is obtained from DJI FC100 equipped with fully charged new battery at a takeoff weight of 149.9kg, flying at a constant optimal speed to 0% charge in a windless environment at 25 ° C at sea level. Results may vary depending on the environment, actual use, and firmware version. Always pay attention to app reminders during actual operation.
Max Hovering Endurance
Under 149.9kg takeoff weight: dual battery 12 minutes, single battery 6 minutes
This data is obtained from DJI FC100 equipped with fully charged new battery at a takeoff weight of 149.9kg, hovering to 0% charge in a windless environment at 25 ° C at sea level. Results may vary depending on the environment, actual use, and firmware version. Always pay attention to app reminders during actual operation.
Max Flight Time
Under 149.9kg takeoff weight: dual battery 14 minutes , single battery 7 minutes.
This data is obtained from DJI FC100 equipped with fully charged new battery at a takeoff weight of 149.9kg, flying at a constant optimal speed to 0% charge in a windless environment at 25 ° C at sea level. Results may vary depending on the environment, actual use, and firmware version. Always pay attention to app reminders during actual operation.
Operating Temperature
-20℃ to 40℃
Measured with estimated solar radiation of 960 W/m 2. Long-term exposure to high temperatures may shorten the service life of certain components.
Ingress Protection Rating
IP55
The protection rating is not permanent and may decline due to aging and wear caused by long-term use. The protection rating does not apply to the propulsion system. After a flight in rain, it is recommended to keep it idling on the ground for 1 minute to prevent corrosion or rust to afflict the propulsion system (precipitation of more than 24.9 mm within 24 hours).
Hovering Accuracy (with strong GNSS signal)
RTK positioning enabled:
± 10 cm (horizontal), ± 10 cm (vertical)
RTK positioning disabled:
± 60 cm (horizontal), ± 30 cm (vertical)
RTK/GNSS Operating Frequency
GPS + Galileo + BeiDou + GLONASS
Max Ascent Speed
5 m/s
Measured in dual battery mode at sea level in a 25℃ windless experimental condition.
Max Descent Speed
5 m/s
Measured in dual battery mode at sea level in a 25℃ windless experimental condition.
Max Horizontal Speed
20 m/s
Measured in dual battery Mode at sea level in a 25℃ windless experimental condition.
Max Flight Altitude（above the sea level）
6,000 m
Drone payload capacity decreases with increasing Taking off Height. 6,000 m above sea level is the maximum safe Height for the drone with two batteries and no payload (Taking off at 4,500 m above sea level).
Maximum Flight Altitude （relative to takeoff point）
1,500 m
flight altitude is constrained by Taking off altitude. The maximum flight altitude for DJI FC100 is 6,000 m.
Max Wind Speed Resistance
12 m/s
The maximum wind resistance during the Taking off and Land Stage is 12 m/s.
Propulsion System
Stator Size
155 × 16 mm
Motor KV Value
60 rpm/V
Propeller Material
Carbon Fiber Composite
Propeller Dimensions
62 inches（1574.8mm）
Propeller Type
Dual-Blade Folded Propeller
Number of Rotors
8 pairs
Safety System
Safety System Type
Front Millimeter-Wave Radar
Rear Radar (Single Board)
Downward Radar (Single Board)
LiDAR
Quad-vision System
FPV
Millimeter-Wave Radar EIRP
<20 dBm (NCC/MIC/KC/CE/FCC)
Operating Temperature
-20° to 40° C (-4° to 104° F)
Operating Environment Requirements
Adequate light and discernible surroundings
Operating Power Consumption
LiDAR: 6.5 W
Front Radar: 18 W
Downward Radar: 5 W
Rear Radar: 5 W
Field of View (FOV)
LiDAR: Vertical 272°, Horizontal 60°
Front Radar: Horizontal 360°, Vertical ±45°
Downward Radar: Left/Right ±12.5°, Front and Back ±22.5°
Rear Radar: Left and Right ±45°, Front/Back ±45°
Quad-vision SystemHorizontal 360°, Vertical 180°
FPV Camera: Horizontal ±86°, Vertical 108°
Measurement Range
≤ 60 m
The effective sensing range and its ability to avoid and bypass obstacles will vary depending on the ambient light, rain, fog, and the material, position, shape, and other properties of the obstacles. Downward sensing is used to assist in Terrain Following flight and altitude stabilization, while other directions assist with obstacle avoidance. AR safety assistance features serve only as supplementary hints, operators must confirm the surrounding environment's safety during operation.
Note 1. Downward sensing assists in Terrain Following flight. If the bottom collides with obstacles, it is considered user responsibility.
Note 2. Due to limitations in safety system performance, the aircraft cannot automatically avoid moving objects, and accidents of this nature will be attributed to user responsibility.
Note 3. Cargo obstacle avoidance is only for auxiliary flight; if the cargo and lifting caboe collide with an obstacle, it is the customer's responsibility.
DJI O4 Video Transmission
Max Transmission Distance
20 km (FCC)
10 km (CE)
12 km (SRRC)
10 km (MIC)
Measured in an unobstructed environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. During your flight, please pay attention to reminder on the DJI Delivery App.
Operating Frequency
2.400 GHz to 2.4835 GHz
5.725 GHz to 5.850 GHz
The supported operating frequency bands and corresponding available range vary by country/region. For Details, please refer to local laws and regulations.
Transmitter Power (EIRP)
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)
Live View Quality
1080p/30fps
Antenna
4 Antennas, 2T4R
4G Enhanced Transmission
Supported
Lighting
Illumination Direction
Forward, Downward
Control mode
Auto, Manual
Max illumination power
46 W（Standard）
Parachute
Model
E2MSF-100A
Touchdown speed
≤ 7 m/s
This data was measured at sea level, 25°C, in a windless condition, with the aircraft at its maximum takeoff weight, and the parachute open at a Height of 100 m.
Parachute Shape
Square
Material
Nylon
Minimum Opening Height
100 m
When open at this height or above which ensures the aircraft reaches a stable velocity upon ground contact.
Operating Temperature
-20° to 40° C (-4° to 104° F)
Ingress Protection Rating
IP55
Mainboard Power-off Battery Life
≥ 1 hour
Memory Card Capacity
Independent Storage, real-time recording of each flight, capable of recording 10 flights.
Alarm method
Buzzer alarm, and lighting alarm
Opening Method
Manual Opening, Auto Opening
Winch System
Model
A2EWH-100A
Dimension
960 mm × 805 mm × 669 mm
Hook charge Method
Wireless charge, Type-C charge
Wireless charge requires the hook to be fully tightened.
Hook Supply Power Time
10 hours
Measured in an ideal windless environment at sea level at 25 °C. Results may vary to different degrees under different external environments, usage patterns, and firmware versions. Please refer to app prompts during actual use.
Cable Length
0-30 meters
Max Retraction Speed
1.2 m/s
Weighing function
Supported
Hook opening and closing function
Supports active control via APP or button
Emergency escape Mode
Cable Discard Escape
Auto Blance Control
Supported
Manual wheel control for retraction
Supported
One-tap release and Retraction
Supported
Intelligent Deceleration Protection
Supported
Lifting System
Model
A2EDL-100A
Dimensions
960 mm × 805 mm × 669 mm
Cable Length
10 meters
Emergency Escape Mode
Cable Cut Escape
Auto Blance Control
Supported
Weighing function
Supported
Recommended Cable Length
10-15 meters
DJI DB2160 Intelligent Flight Battery
Weight
14.7 kilograms
Capacity
41 Ah
Standard Voltage
52 V
Remote Controller
Model
TKPL 2
App
DJI Delivery App
Screen
7-inch LCD touchscreen; Resolution: 1920 × 1200; LIGHTEN: 1,400 cd/m²
Charging Environment Temperature
5° to 40° C (41° to 104° F)
Built-in Battery Life
3.8 hours
External Battery Life
3.2 hours
Charging Method
Use a USB-C fast charging charger with a maximum power of no less than 65 W (maximum voltage of 20 V). A DJI portable charger is recommended.
Charging Time
2 hours with built-in battery, 2.5 hours with built-in and external battery (shutdown status according to official charging method)
4G Enhanced Transmission
Supported
RTK High-Precision Positioning System Module
Supported
Operating Temperature
-20° to 50° C (-4° to 122° F)
Dual Operator Mode
Supported
The second remote controller needs to be purchased separately.
SDK
PSDK Communication Interface
Eport-Lite
When connecting a third-party payload externally, an additional purchase of the DJI FC100 PSDK Connection Cable Combo is required.
PSDK Power Interface
Supports 3000 W
When connecting a third-party payload externally, an additional purchase of the DJI FC100 PSDK Connection Cable Combo is required.
C12000 Intelligent Power Supply
Charger Model
CSX901-12000
Dimensions
456 mm × 291 mm × 107 mm
Weight
13.13 kg
Input Voltage
Three-phase AC input: 175-520 V
Single-phase AC input: 200-264 V
Output Voltage
62 V
Rated Output Current
194 A
Rated Power
12,000 W (three-phase 380 V input)
3,000 W (single-phase 220 V input)
Actual output power may vary due to local power grid conditions, such as distance, Cable material, and wire gauge.
Charging Time
9 minutes
Time to recharge from 30% to 95% battery level at sea level, with an environmental temperature between 15° and 40° C. Fast recharge is supported when battery cell temperature is within the Range of 15° to 75° C. Charging Time may vary depending on factors such as input power, ASL, and initial charge level.
Protection Functions
Over-temperature, over-voltage, under-voltage, short-circuit, fan stall, and other protection functions
Operating Temperature
0° to 40° C (32° to 104° F)
Output Channels
1
D14000iE Multifunctional Inverter Generator
Output Channels
1. DC recharge output 42-61.6V/11500W
2. Air-cooled radiator charge 12V/6A
3. AC Output 220V/1500W
The charging station's output power is affected by factors such as altitude, fuel quality, etc.
Charging Time
9 minutes
Time to recharge from 30% to 95% battery level at sea level, with an environmental temperature between 15° and 40° C. Fast recharge is supported when battery cell temperature is within the Range of 15° to 75° C. Charging Time may vary depending on factors such as input power, ASL, and initial charge level.
Fuel tank capacity
30L
Starting method
One-button start
Operating Temperature
0° to 40° C (32° to 104° F)
Dimensions
757 mm × 704 mm × 677 mm
Weight
87±0.5 kg
Weight measured at sea level Height. The D14000iE All-around Inverter Charging Station's weight includes 2 kg for the wheels and handle, which can be optionally attached or detached during use.
Fuel type
92 octane gasoline or higher
Reference fuel consumption
500 mL/kWh
Engine Oil Capacity
1.3L
Engine Oil Type
DJI Dedicated Engine Oil S10W-40
D-RTK 3 Multifunctional Station (Optional)
Dimensions
Diameter: 163 × 89 mm (without OcuSync Directional Antennas)
Weight
Approximately 1.26 kg
Operating Frequency
Relay Station Mode:
O4: 2.4 GHz/5.2 GHz/5.8 GHz
Base Station Mode:
O4: 2.4 GHz/5.8 GHz
Relay Station Range Enhancement
Relay Station performance improvement:
Addresses severe obstructions (e.g., Buildings, mountains): 3 to 5 times performance improvement
Addresses minor obstructions (e.g., trees, glass): 1 to 3 times performance improvement
The relay station needs to be deployed in a high, unobstructed location free from interference.
built-in battery operating Time (at room temperature)
D-RTK 3 Multifunctional Station:
Relay Station: 4 hours
Base Station: 7 hours
At low temperatures, the range performance may decrease. It is recommended to use a Power Supply that supports the USB PD3.0 Protocol for charge.
Ingress Protection Rating
D-RTK 3 Multifunctional Station: IP67
Ensure all rubber plug interfaces on the body are properly mounted.
Positioning Accuracy
Base Station Mode and Relay Station Mode
Base Station Positioning Error:
Single Point Accuracy (Uncalibrated):
Horizontal: 1.5 m (RMS)
Vertical: 3.0 m (RMS)
Satellite-based Differential Accuracy:
Convergence Time: 20 min
Horizontal: 30 cm (RMS)
Vertical: 40 cm (RMS)
* Measurement accuracy depends on various factors. This value is obtained under normal conditions with an unobstructed view, good satellite distribution, low ionospheric activity, and no electromagnetic interference or multipath effects.
DJI Battery Incubator(Optional)
Operating Temperature
-20° to 40° C (-4° to 104° F)
