Specs
Aircraft
Weight
42.5 kg (without battery)
65 kg (with two DB2000 batteries)
Max Takeoff Weight
95 kg (with cargo at sea level）
Max Diagonal Wheelbase
2200 mm
Dimensions
1590 x 1900 x 947 mm
(LxWxH) (arms unfolded, propellers folded)
2800x3085x947 mm
(LxWxH) (arms & propellers unfolded)
1115x760x1027 mm
(LxWxH) (arms & propellers folded)
Folding Method
Towards body
Loadable Battery Quantity
2
Hovering Endurance (empty weight, with max battery capacity)
29 mins (dual battery mode)
15 mins (single battery mode)
*The data was collected in controlled conditions: zero altitude and a windless environment. For reference only.
Hovering Endurance (max weight, with max battery capacity)
18 mins (30 kg weight load, dual battery mode)
8 mins (40 kg weight load, single battery mode)
*The data was collected in controlled conditions: zero altitude and a windless environment. For reference only.
Max Flight Distance (empty weight, with max battery capacity)
28 km (dual battery mode)
12 km (single battery mode)
*The data was collected in controlled conditions: zero altitude and windless environment, at a constant speed of 15m/s. For reference only.
Max Flight Distance (max weight, with max battery capacity)
16 km (30 kg weight load, dual battery mode)
8 km (40 kg weight load, single battery mode)
*The data was collected in controlled conditions: zero altitude and windless environment, at a constant speed of 15 m/s. For reference only.
Max Flight Time (max weight, with max battery capacity)
18 mins (30 kg weight load, dual battery mode)
9 mins (40 kg weight load, single battery mode)
*The data was collected in controlled conditions: zero altitude and a windless environment, at a constant speed of 15 m/s. For reference only.
Operating Temperature
-20° to 45° C
Ingress Protection Rating
IP55
Hovering Accuracy (with strong GNSS signal)
RTK positioning enabled:
±10 cm horizontal, ±10 cm vertical
RTK positioning disabled:
±60 cm horizontal and ±30 cm vertical (radar enabled: ±10 cm)
RTK/GNSS Operating Frequency
RTK: GPS L1/L2, Galileo F1/F2, BeiDou B1I/B2I/B3I, Galieo E1/E5b, QZSS L1/L2
GNSS: GPS L1, BeiDou B1I, Galileo F1, Galieo E1, QZSS L1
Max Pitch Angle
30°
Max Ascent Speed
5 m/s
*The data was collected in controlled conditions: zero altitude and a windless environment, with a 30 kg payload. For reference only.
Max Descent Speed
3 m/s (vertical)
5 m/s (tilted)
*The data was collected in controlled conditions: zero altitude and a windless environment, with a 30 kg payload. For reference only.
Max Horizontal Speed
20 m/s
*The data was collected in controlled conditions: zero altitude and a windless environment, with a 30 kg payload, for reference only.
Max Flight Altitude
6000 m (without payload)
Max Wind Speed Resistance
12 m/s
*The data was collected in controlled conditions: zero altitude and a windless environment, with a 30 kg payload. For reference only.
Propulsion System
Stator Size
100x33 mm
Motor KV Value
48 rpm/V
Max Motor Power
4000 W/rotor
Propellers Material
Carbon fiber composite
Propellers Diameter
54 inch
Propellers Type
Foldable double-blade propellers
Main-rotor Diameter
1375 mm
Rotor Quantity
8
LED Light
Effective Illumination Distance
10 m
Illumination Mode
60 Hz, automatically switch on according to ambient light
DJI O3 Image Transmission
Model
Pigeon (with DDR)-2T4R
Signal Effective Distance
20 km (FCC)
8 km (CE/SRRC/MIC)
*Measured with FCC compliance in unobstructed environments with typical interference. Data is for reference only. The actual transmission distance may vary depending on the environment's obstruction and interference conditions. Please pay attention to reminders in the app.
O3 Operating Frequency
2.4000 to 2.4835 GHz
5.725 to 5.850 GHz
*Some countries or regions do not support the 5.8 GHz frequency band. Please refer to local flight laws and regulations for details.
EIRP
2.400 GHz - 2.4835 GHz:
<33 dBm（FCC）
<20 dBm（CE/SRRC/MIC）
5.725 GHz - 5.850 GHz：
<33 dBm（FCC）
<30 dBm（SRRC）
<14 dBm（CE）
Data Security
AES-256
ADS-B
Supported
Forward and Backward Active Phased Array Radar
Model Number
RD241608RF (forward)
RD241608RB (backward)
Altitude Detection
Fixed altitude range: 1.5-200 m
Rear Obstacle Avoidance
Sensible distance (rear): 1.5-50 m
FOV Forward: 360° horizontal, ±45° vertical，±45°upward
Backward: ±45° horizontal, 360° vertical
Operating conditions: Available during takeoff, landing, and ascending when an obstacle is more than 1.5 m away from the aircraft
Safe distance: 3.5 m (distance between the propeller tip and obstacle when the aircraft is hovering after braking)
Sensing direction: multi-direction
Binocular Vision System
FOV
Horizontal: 90; Vertical: 106°
Work Environment Requirements
Normal lighting with clearly textured surfaces
FPV Camera
Resolution
1920x1440
DFOV
149°
Frame Rate
30fps
Type
Full HD FPV Single Axis Gimbal Camera
Fill Light
Supported
Cargo Case
Dimension
754x472x385 mm (LxWxH)
Inner Space
573x416x305 mm (LxWxH)
Material
EPP plus aluminum alloy frame
Weighing Feature
Supported
Weight
Approx. 3 kg
Load Capacity
0-40 kg
Parachute
Max Payload
≤ 95 kg
Dimension
300x200x120 mm (LxWxH)
Weight
Approx. 2.1 kg
Automatic Reaction Time
Approx. 1000 ms
Descending Speed
≤ 6 m/s (at sea level, no wind)
Parachute Shape
Square
Material
Nylon
Surface Area
Approx. 22 ㎡
Minimum Opening Height
60 m
Operating Temperature
-20° to 45° C
Ingress Protection Rating
IP55
Mainboard Power-off Battery Life
≥ 1 hour
Memory Card Capacity
Real-time record for 10 flights
Buzzar Alarm
Supported
Lighting Alarm
Supported
Manually Opening
Supported
Automatic Opening
Supported
Winch System (Optional)
Model
A2EWI-30A
Dimension
252x195x193 mm (LxWxH)
Body Weight
2.5 kg (without clump and couple)
Clump Weight
1.9 kg
Couple Weight
0.6 kg
Touchdown Release Feature
Supported
Payload Capacity
5-30 kg (dual battery)5-40 kg (single battery)
Cable Length
20 m
Max Retraction Speed
0.8 m/s
Operating Temperature
-20° to 45° C
Ingress Protection Rating
IP55
Weighing Function
Supported
Cut Cable Protection
Supported
Swing Control Feature
Supported
Manual Operation
Supported
Automatic Operation
Supported
Deceleration Protection
Supported
DJI DB2000 Intelligent Battery
Model
DB2000
Capacity
38000 mAH
Nominal Voltage
52.22 V
Type
14S1P
Energy
1984.4 Wh
Weight
Approx. 11.3 kg
Installation Method
Plug
Dimension
316x152x279 mm (LxWxH)
Operating Temperature
-20° to 45° C
Charging Rate
5 to 15° C: 1.0C15 to 45° C: 2.5C
Max Charging Power
5700 W
Automatic Heating Feature
Supported (when the battery temperature is below 10° C, pressing and holding the button or turning on the drone will activate the self-heating function. When the battery temperature is below 20° C, connecting the charger to the battery will activate the self-heating function. Charging and discharging in a low-temperature environment may reduce the battery's lifespan)
DJI C8000 Intelligent Charger
Model
CHX101-7000
Input
90-264 V AC
Output
42-59.92 V DC
Max Output Power
7200 W (Dual input)3600 W (Single input)
Output Channel Quantity
2
Protection Feature
The feature is designed to respond to issues including overheating, overvoltage, undervoltage, short circuits, fan stalls, etc.
Operating Temperature
-20° to 45° C
Charging Security
Connector protection feature available
Remote Controller
Type
DJI RC Plus
APP
DJI Pilot 2
Operating Frequency
2.400-2.483 GHz
5.725-5.850 GHz
EIRP
2.400-2.4835 GHz:
<33 dBm（FCC）
<20 dBm（CE/SRRC/MIC）
5.725-5.850 GHz:
<33 dBm（FCC）
<23 dBm（SRRC）
<14 dBm（CE）
Operating Temperature
-20° to 50° C
Charging Environment Temperature
5° to 40° C
Built-in Battery Life
3.3 hours
External Battery
2.7 hours
Charging Method
Use a USB-C fast charging charger with a maximum power of no less than 65 W (maximum voltage of 20 V). A DJI portable charger is recommended.
Charging Time
2 hours with built-in battery, 2.5 hours with built-in and external battery (shutdown status according to official charging method)
Ingress Protection Rating
IP54
Video Output Interface
HDMI
Wi-Fi Protocol
Wi-Fi 6
Wi-Fi Working Frequency
2.4000-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Bluetooth Protocol
Bluetooth 5.1
Bluetooth Working Frequency
2.4000 - 2.4835 GHz
EIRP
<10 dBm
GNSS
GPS+Galileo+BeiDou
Screen
7.02 inch touch LCD display screen, resolution 1920*1200, brightness 1200 nits
Dual Operator Mode
Supported
