Specs
Aircraft
Takeoff Weight
Approx. 1063 g
Product weight may vary due to differences in batch materials and other factors.
Dimensions
Folded (with propellers): 257.6×124.8×106.6 mm (L×W×H)
Folded (without propellers): 257.6×124.8×103.4 mm (L×W×H)
Unfolded (without propellers): 328.7×390.5×135.2 mm (L×W×H)
Max Ascent Speed
10 m/s (Sport Mode)
6 m/s (Normal Mode)
6 m/s (Cine Mode)
Max Descent Speed
10 m/s (Sport Mode)
6 m/s (Normal Mode)
6 m/s (Cine Mode)
Max Horizontal Speed
At sea level, in windless conditions:
25 m/s* (Sport Mode)
15 m/s (tracking status)
At sea level, with 2 m/s tailwind, while flying in the same direction as the wind:
27 m/s* (Sport Mode)
15 m/s (tracking status)
* Measured in a wind tunnel test environment with the aircraft taking off from an altitude of 0 m and ascending vertically by 1.5 m in Sport mode. Data is for reference only. Always pay attention to reminders on the camera view during your flight.
Max Takeoff Altitude
6000 m
Maximum takeoff altitude is 3000 m with DJI Mavic 4 Pro Propeller Guards.
Max Flight Time
51 minutes
Measured by the aircraft flying forward at a constant speed of 32.4 kph in a windless environment at sea level, with Obstacle Avoidance Action set to Brake, in photo mode, and from 100% battery level until 0%. Actual experience may vary depending on the environment, usage, and firmware version.
Max Hovering Time
45 minutes
Measured by the aircraft hovering in a windless environment at sea level, with Obstacle Avoidance Action set to Brake, in photo mode, and from 100% battery level until 0%. Actual experience may vary depending on the environment, usage, and firmware version.
Max Flight Distance
41 km
Measured by the aircraft flying forward at a constant speed of 54 kph in a windless environment at sea level, with Obstacle Avoidance Action set to Brake, in photo mode, and from 100% battery level until 0%. Actual experience may vary depending on the environment, usage, and firmware version.
Max Wind Speed Resistance
12 m/s (39.4 ft/s)
Max Pitch Angle
35°
Operating Temperature
-10 °C to 40 °C (14 °F to 104 °F)
Global Navigation Satellite System
GPS + Galileo + BeiDou
Hovering Accuracy Range
Vertical:
±0.1 m (with vision positioning)
±0.5 m (with satellite positioning)
Horizontal:
±0.3 (with vision positioning)
±0.5 m (with satellite positioning)
Internal Storage
Mavic 4 Pro: 64GB (available storage space is approximately 42GB)
Mavic 4 Pro 512GB (Creator Combo): 512GB (available storage space is approximately 460GB)
Class
C2 (EU)
Camera
Image Sensor
Hasselblad Camera: 4/3 CMOS, Effective Pixels: 100 MP
Medium Tele Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP
Tele Camera: 1/1.5-inch CMOS, Effective Pixels: 50 MP
Lens
Hasselblad Camera
FOV: 72°
Format Equivalent: 28 mm
Aperture: f/2.0 to f/11
Focus: 2 m to ∞
Medium Tele Camera
FOV: 35°
Format Equivalent: 70 mm
Aperture: f/2.8
Focus: 3 m to ∞
Tele Camera
FOV: 15°
Format Equivalent: 168 mm
Aperture: f/2.8
Focus: 3 m to ∞
ISO Range
Hasselblad Camera
Video
Normal:
100-12800 (Normal)
400-6400 (D-Log)
100-6400 (D-Log M)
100-6400 (HLG)
Slow Motion:
100-6400 (Normal)
400-3200 (D-Log)
100-3200 (D-Log M)
100-3200 (HLG)
100-6400 (25 MP)
100-3200 (100 MP)
Medium Tele Camera and Tele Camera
Video
Normal:
100-12800 (Normal)
400-3200 (D-Log)
100-3200 (D-Log M)
100-3200 (HLG)
Slow Motion:
100-6400 (Normal)
400-3200 (D-Log)
100-3200 (D-Log M)
100-3200 (HLG)
100-6400 (12 MP)
100-3200 (48 MP and 50 MP)
Shutter Speed
Hasselblad Camera
25MP Single Shot: 1/16000-16 s (over 2 s for simulated long exposure)
100MP Single Shot: 1/8000-8 s
25 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/16000-8 s
100 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/8000-8 s
Medium Tele Camera
12 MP Single Shot: 1/16000-8 s (over 2 s for simulated long exposure)
48 MP Single Shot: 1/8000-2 s
12 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/16000-2 s
48 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/8000-2 s
Tele Camera
12.5 MP Single Shot: 1/16000-8 s (over 1 s for simulated long exposure)
50 MP Single Shot: 1/16000-2 s
12.5 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/16000-2 s
50 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/16000-2 s
Max Image Size
Hasselblad Camera: 12288 × 8192
Medium Tele Camera: 8064 × 6048
Tele Camera: 8192 × 6144
Still Photography Modes
Hasselblad Camera
Single Shot: 25 MP, 100 MP
Automatic Exposure Bracketing (AEB): 25 MP, 3/5/7 frames at 0.7 EV step; 100 MP, 3/5 frames at 0.7 EV step
Burst Shooting: 25 MP, 3/5/7 frames; 100 MP, 3/5 frames
Timed: 25 MP, 1 (Mavic 4 Pro 512GB)/2/3/5/7/10/15/20/30/60 seconds; 100 MP, 2 (Mavic 4 Pro 512GB)/3 (Mavic 4 Pro 512GB)/5 (Mavic 4 Pro 512GB)/7 (Mavic 4 Pro 512GB)/10/15/20/30/60 seconds
Medium Tele Camera
Single Shot: 12 MP, 48 MP
Automatic Exposure Bracketing (AEB): 12 MP, 3/5/7 frames at 0.7 EV step; 48 MP, 3/5/7 frames at 0.7 EV step
Burst Shooting: 12 MP, 3/5/7 frames; 48 MP, 3/5/7 frames
Timed: 12 MP, 1 (Mavic 4 Pro 512GB)/2/3/5/7/10/15/20/30/60 seconds; 48 MP, 1 (Mavic 4 Pro 512GB)/2 (Mavic 4 Pro 512GB)/3 (Mavic 4 Pro 512GB)/5/7/10/15/20/30/60 seconds
Tele Camera
Single Shot: 12.5 MP, 50 MP
Auto Exposure Bracketing (AEB): 12.5 MP, 3/5/7 frames at 0.7 EV step; 50 MP, 3/5/7 frames at 0.7 EV step
Burst Shooting: 12.5 MP, 3/5/7 frames; 50 MP, 3/5/7 frames
Timed: 12.5 MP, 1 (Mavic 4 Pro 512GB)/2/3/5/7/10/15/20/30/60 seconds; 50 MP, 1 (Mavic 4 Pro 512GB)/2 (Mavic 4 Pro 512GB)/3 (Mavic 4 Pro 512GB)/5/7/10/15/20/30/60 seconds
Photo Format
JPEG
DNG (RAW)
Video Resolution
Hasselblad Camera
H.264 ALL-I/H.265 Standard*
6K: 6016×3384@24/25/30/48/50/60fps
DCI 4K: 4096×2160@24/25/30/48/50/60/120**fps
4K: 3840×2160@24/25/30/48/50/60/120**fps
FHD: 1920×1080@24/25/30/48/50/60fps
4K Vertical Shooting: 2160×3840@24/25/30/48/50/60fps
H.264 Standard
FHD: 1920×1080@24/25/30/48/50/60fps
Medium Tele Camera
H.264 ALL-I/H.265 Standard*
4K: 3840×2160@24/25/30/48/50/60/120**fps
FHD: 1920×1080@24/25/30/48/50/60fps
2.7K Vertical Shooting: 1512×2688@24/25/30/48/50/60fps
H.264 Standard
FHD: 1920×1080@24/25/30/48/50/60fps
2.7K Vertical Shooting: 1512×2688@24/25/30/48/50/60fps
Tele Camera
H.264 ALL-I/H.265 Standard*
4K: 3840×2160@24/25/30/48/50/60/100**fps
FHD: 1920×1080@24/25/30/48/50/60fps
2.7K Vertical Shooting: 1512×2688@24/25/30/48/50/60fps
H.264 Standard
FHD: 1920×1080@24/25/30/48/50/60fps
2.7K Vertical Shooting: 1512×2688@24/25/30/48/50/60fps
* Only Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
** Recording frame rates. The corresponding video plays as a slow-motion video.
Video Format
MP4 (H.264 ALL-I/H.264 Standard/H.265 Standard)
Only Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
Max Video Bitrate
H.264 Standard Bitrate: 90 Mbps
H.265 Standard Bitrate: 180 Mbps
H.264 ALL-I Bitrate: 1200 Mbps
Only Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
Supported File System
exFAT
Color Mode and Sampling Method
Hasselblad Camera
Normal Color:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
8-bit 4:2:0 (H.264 Standard)
HLG/D-Log M/D-Log:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
Medium Tele Camera
Normal Color:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
8-bit 4:2:0 (H.264 Standard)
HLG/D-Log M/D-Log:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
Tele Camera
Normal Color:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
8-bit 4:2:0 (H.264 Standard)
HLG/D-Log M/D-Log:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
Only Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
Digital Zoom
Hasselblad Camera: 1x to 2.5x
Medium Tele Camera: 2.5x to 6x
Tele Camera: 6x to 24x
Gimbal
Stabilization
3-axis mechanical gimbal (tilt, roll, pan)
Mechanical Range
Tilt: -164° to 160°
Roll: -90° to 450°
Pan: -22° to 22°
Controllable Range
Tilt: -90° to 70°
Roll: -40° to 400°
Max Control Speed
Tilt: 100°/s
Roll: 100°/s
Angular Vibration Range
Hovering Without Wind: ±0.001°
Normal Mode: ±0.003°
Sport Mode: ±0.005°
Sensing
Sensing Type
Omnidirectional binocular vision system, supplemented with forward-facing LiDAR and an infrared sensor at the bottom of the aircraft
Forward
Measurement Range:
0.5-24 m
Detection Range:
0.5-200 m
Effective Sensing Speed:
Flight Speed ≤ 18 m/s
FOV:
Horizontal 180°, Vertical 180°
Backward
Measurement Range:
0.5-22 m
Detection Range:
0.5-200 m
Effective Sensing Speed:
Flight Speed ≤ 18 m/s
FOV:
Horizontal 180°, Vertical 180°
Lateral
Measurement Range:
0.5-21 m
Detection Range:
0.5-200 m
Effective Sensing Speed:
Flight Speed ≤ 18 m/s
FOV:
Horizontal 180°, Vertical 180°
Upward
Measurement Range:
0.5-18 m
Effective Sensing Speed:
Flight Speed ≤6 m/s
FOV:
Horizontal 90°, Vertical 90°
Downward
Measurement Range:
0.5-17 m
Effective Sensing Speed:
Flight Speed ≤6 m/s
FOV:
Horizontal 180°, vertical 180°
3D Infrared Sensing System
Forward-Facing LiDAR
Measurement Range (nighttime): 0.5-25 m (reflectivity > 10%)
FOV: Up and Down 60°, Left and Right 60°
Downward-Facing Infrared Sensor
Measurement Range: 0.3-8 m (reflectivity > 10%)
FOV: Front and Back 60°, Left and Right 60°
Operating Environment
Forward, Backward, Left, Right, and Upward:
Surfaces with discernible patterns, adequate lighting (lux > 0.1, urban lighting environment).
Downward:
Surfaces with discernible patterns, diffuse reflectivity > 20% (e.g. walls, trees, people), and adequate lighting (lux > 0.1, urban lighting environment).
Video Transmission
Video Transmission System
O4+
Live View Quality
Remote Controller: 1080p/30fps, 1080p/60fps
Operating Frequency
2.4000-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHz
Operating frequency allowed varies among countries and regions. Please refer to local laws and regulations for more information.
Transmitter Power (EIRP)
2.4 GHz:
< 33 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)
5.1 GHz:
< 23 dBm (CE)
5.8 GHz:
< 33 dBm (FCC)
< 14 dBm (CE)
< 30 dBm (SRRC)
Max Transmission Distance (unobstructed, free of interference)
FCC: 30 km
CE: 15 km
SRRC: 15 km
MIC: 15 km
Measured in an open, outdoor environment without interference or obstructions and represents the farthest communication range under each standard. The actual max transmission distance during flight is limited by the drone's max flight distance. Always pay attention to RTH reminders on the camera view during your flight.
Max Transmission Distance (unobstructed, with interference)
Strong Interference (urban landscape): Approx. 1.5-6 km
Medium Interference (suburban landscape): Approx. 6-15 km
Low Interference (suburb/seaside): Approx. 15-30 km
Measured under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Transmission Distance (obstructed, with interference)
Low Interference and Obstructed by Buildings: Approx. 0-0.7 km
Low Interference and Obstructed by Trees: Approx. 0.7-4.5 km
Measured under FCC standard in obstructed environments with typical low interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Download Speed
O4+: 10 MB/s*
Wi-Fi 6: 80 MB/s*
* Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz, with footage saved to the internal storage. Download speeds may vary depending on the actual conditions.
Lowest Latency
Compatible with DJI RC 2/ DJI RC Pro 2 Remote Controller: approx. 130 ms
Depending on the actual environment and mobile device.
Antenna
6 antennas, 2T4R
Wi-Fi
Protocol
802.11 a/b/g/n/ac/ax
Operating Frequency
2.4000-2.4835 GHz
5.725-5.850 GHz
Operating frequency allowed varies among countries and regions. Please refer to local laws and regulations for more information.
Transmitter Power (EIRP)
2.4 GHz:
< 23 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)
5.8 GHz:
< 23 dBm (FCC/SRRC)
< 14 dBm (CE)
Bluetooth
Protocol
Bluetooth 5.1
Operating Frequency
2.4000-2.4835 GHz
Operating frequency allowed varies among countries and regions. Please refer to local laws and regulations for more information.
Transmitter Power (EIRP)
< 10 dBm
Battery
Capacity
6654 mAh
Weight
Approx. 332 g
Nominal Voltage
14.32 V
Max Charging Voltage
17.2 V
Battery Type
Li-ion 4S
Chemical System
LiNiMnCoO2
Energy
95.3 Wh
180
5° to 40° C (41° to 104° F)
Charging Time
Using the DJI Mavic 240W Power Adapter with no other devices connected to the charger or the Charging Hub's USB-C port
From 0% to 100%: 1 battery takes about 51 minutes, 3 batteries take about 90 minutes (200 V to 240 V input) or about 110 minutes (100 V to 127 V input)
Using DJI 100W USB-C Power Adapter
From 0% to 100%: 1 battery takes about 80 minutes
Charging via the aircraft (65W max charging power)
From 0% to 100%: 115 minutes
Charging time is measured in a test environment with a temperature of 25°C. Actual charging time may increase due to higher ambient temperatures or variations in mains voltage between regions.
Battery Charging Hub
Input
USB-C Port: 5 V to 20 V, max 5 A
Mini SDC Port: 11.2 V to 17.6 V, max 15 A
Output
Battery Port: 10 V to 17.2 V, max 12 A
Rated Power
USB-C Port: Supports up to 100 W
Mini SDC Port: Supports up to 240 W/15 A
Charging Type
When used with the DJI Mavic 240W Power Adapter: Supports parallel charging of three batteries (The Parallel Charging Hub will prioritize the battery with the lowest charge and switch to parallel charging once all three batteries reach the same charge level.)
When used with the DJI 100W USB-C Power Adapter: Charges three batteries in sequence.
Compatibility
DJI Mavic 4 Pro Intelligent Flight Battery
Storage
Recommended microSD Cards
Lexar Silver plus 64GB A2 V30 microSDXC
Lexar Silver plus 128GB A2 V30 microSDXC
Lexar Silver plus 256GB A2 V30 microSDXC
Lexar Silver plus 512GB A2 V30 microSDXC
Lexar Silver plus 1TB A2 V30 microSDXC
Kingston CANVAS GO! Plus 64GB A2 V30 microSDXC
Kingston CANVAS GO! Plus 128GB A2 V30 microSDXC
Kingston CANVAS GO! Plus 256GB A2 V30 microSDXC
Kingston CANVAS GO! Plus 512GB A2 V30 microSDXC
